GENERAL FEATURES
*High resolution LCD display, 5.7 inches.
*Multi-reading feature allows auto-read, timed-read and continuous-read.
*Automatic/Manual temperature compensation ensures accurate results.
*Auto-hold feature senses and locks the measurement endpoint.
*Data Storage 500 sets (GLP-compliant).
*Support for USB or RS-232 communication.
*Reset feature automatically resumes all settings back to factory default options.
*IP54 waterproof.
pH
*1-5 points calibration with Standard Recognition.
*Selectable pH buffer groups, including NIST, DIN, GB, USA.
*Automatic electrode diagnosis with pH slope and offset display. Ion
*1-5 points calibration.
*Selectable measurement unit, including μg/L, mg/L, g/L, mmol/L, pX, ppm, ppb, etc.
*Multi-measurement modes are supported, including Direct Reading mode, Standard Addition mode, Sample Addition mode and GRAN mode.
*Over 10 methods are built-in, including F-, Cl-, Br-, I-, NO3-, BF4-, NH4+, K+, Na+, Ca2+, Cu2+, Pb2+, Ag+ and etc., user-defined method is supported.
Conductivity
*1-3 points calibration with Standard Recognition.
*Settable parameters, including cell constant, temperature compensation coefficient and TDS factor.
*Temperature compensation type (none, linear, pure water).
DO
*Support for air-saturated water or zero oxygen calibration.
*Auto barometric pressure compensation
*Manual Salinity Factor Correction
*Selectable pressure unit, including kPa, mbar, Torr, Atm.
Includes
*E-301-QC 3 in 1 pH composite electrode
*DJS-1VTC EC electrode
*DO-958-Q polarographic DO electrode
*NIST pH standard solution(4.01, 7.00, 10.01) , 50ml/vial
*1413μS/cm EC standard solution, 50ml, 1 vial
*REX-5 electrode stand
GENERAL FEATURES
*High resolution LCD display, 5.7 inches.
*Multi-reading feature allows auto-read, timed-read and continuous-read.
*Automatic/Manual temperature compensation ensures accurate results.
*Auto-hold feature senses and locks the measurement endpoint.
*Data Storage 500 sets (GLP-compliant).
*Support for USB or RS-232 communication.
*Reset feature automatically resumes all settings back to factory default options.
*IP54 waterproof.
|
Model
|
M300F
|
|
|
Parameters
|
pH/EC/ISE/DO/Temp. (mV/ORP/pX/Resistivity/TDS/Sal./DO Saturation)
|
|
|
pH
|
Range
|
-2.00 to 20.00pH
|
|
Resolution
|
0.1, 0.01 pH
|
|
|
Accuracy
|
±0.01 pH
|
|
|
Calibration Points
|
Up to 5
|
|
|
Standard Customization
|
Yes
|
|
|
Standard Recognition
|
NIST, GB, USA and DIN buffers
|
|
|
Slope Limit
|
Yes
|
|
|
mV
|
Range
|
-2000.0 to 2000.0 mV
|
|
Resolution
|
0.1 mV
|
|
|
Accuracy
|
±0.3 mV or ±0.1%
|
|
|
pX
|
Range
|
-2.00 to 20.00 pX
|
|
Resolution
|
0.1, 0.01 pX
|
|
|
Accuracy
|
±0.01 pX
|
|
|
Calibration Points
|
Up to 5
|
|
|
ISE
|
Range
|
1.000e-9 to 9.999e+9
|
|
Unit
|
mol/L, mmol/L, g/L, mg/L, μg/L, ppm, ppb
|
|
|
Resolution
|
Up to 4 significant digits
|
|
|
Accuracy
|
±0.5%
|
|
|
Calibration Points
|
Up to 5
|
|
|
Conductivity
|
Range
|
0.000 μS/cm to 1000 mS/cm
|
|
Resolution
|
0.001 μS/cm minimum,
various with range selection |
|
|
Accuracy
|
±1.0% FS
|
|
|
Reference Temperature
|
20, 25 ºC
|
|
|
Calibration Points
|
Up to 3
|
|
|
Standard Recognition
|
84μS/cm, 1413μS/cm, 12.88mS/cm
|
|
|
Resistivity
|
Range
|
5.00 Ω·cm~20.00 MΩ·cm
|
|
Resolution
|
0.01 Ω·cm minimum
|
|
|
Accuracy
|
±1.0% FS
|
|
|
TDS
|
Range
|
0.00 ppm~300 ppt
|
|
Resolution
|
0.01mg/L minimum, various with range selection
|
|
|
Accuracy
|
±1.0% FS
|
|
|
Salinity
|
Range
|
0.0~80.0 ppt
|
|
Resolution
|
0.1ppt
|
|
|
Accuracy
|
±2ppt
|
|
|
Dissolved
Oxygen Concentration |
Range
|
0.00 to 20.00 ppm
|
|
Resolution
|
0.01 ppm
|
|
|
Accuracy
|
±0.10 ppm
|
|
|
Calibration Points
|
Air-saturated water or zero point
|
|
|
Barometric Compensation
|
Yes
|
|
|
Manual Salinity Factor Correction
|
Yes
|
|
|
Saturation
|
Range
|
(0.0 to 200.0)%
|
|
Resolution
|
0.1%
|
|
|
Accuracy
|
±2.0%
|
|
|
Temperature
|
Range
|
-5 to 110 ºC, 23 to 230 ºF
|
|
Unit
|
ºC, ºF
|
|
|
Resolution
|
0.1
|
|
|
Accuracy
|
±0.2ºC
|
|
|
Measurement
|
Reading Mode
|
Auto Read (Fast, Medium, Slow), Timed, Continuous
|
|
Reading Prompts
|
Reading, Stable, Locked
|
|
|
Temp. Compensation
|
ATC, MTC
|
|
|
Data management
|
Data Storage
|
500 results each
|
|
GLP Features
|
Yes
|
|
|
Inputs
|
pH Electrode
|
BNC(Q9)
|
|
DO with Temp. Probe
|
4-pin aviation connector
|
|
|
Conductivity with Temp. Probe
|
5-pin aviation connector
|
|
|
Outputs
|
USB
|
PC
|
|
RS 232
|
printer
|
|
|
Display options
|
Backlight
|
Yes
|
|
Auto Shutdown
|
1~60 min, off
|
|
|
IP Rating
|
IP54
|
|
|
Date and Time
|
Yes
|
|
|
General
|
Power
|
AC Adapter, 100-240V AC input, DC9V output
|
|
Dimensions
|
242×195×68 mm
|
|
|
Weight
|
900g (1.98 lb)
|
|
|
Dimensions (Carton)
|
370×305×330 mm
|
|
|
Weight (Gross)
|
3.5 kg
|
|
