For determination of abrasion resistance of rubber tires, rubber overshoes, adhesive tape, to identify the quality of rubber products. Rubber compounds were friction with the cloth in a certain load to determine the amount of abrasion of the sample within a predetermined stroke.
Standard
ISO4649, DIN 53516
Technical parameters:
| Sample load | 2.5N, 5N,10N |
| Stroke | 40m or 20m |
| Roller speed | 40 ± 1r/min |
| Roller diameter | Ф150 ± 0.2mm |
| Roller length | 460mm |
| Sample dia. | Ф16 ± 0.2mm |
| Power | AC220V ± 10% 50Hz |
| Dimension | 700mm × 340mm × 300mm |
| Weight | 63kg |
